Geomembrane Welding Machine

Hand Extruder

Geomembrane welding machineHand extruder’s Applications:
This series of hand extruder is the first one to have a digital disply control,360-degree rotating welding head,the motor cold start protection,independent heating of welding rod and membrane material and other functions.
Applicableto welding PE,PP,PVC,PVDF and other hot melt material....Chat Now

LST600 Hand extruder

This series of hand extruder is the first one to have a digital display control, 360-degree rotating welding head, the motor cold start protection, independent heating of welding rod and membrane material and other functions. Applicable to welding PE PP PVC PVDF and other hot melt material.



Tips:
1.This welder start to weld when the temperature up to 270°c

2.This welder is welded with PE or PP welding rod 3.0-3.5mm.
3. Any customized demands, you can ask us directly. We have professional technicians team.







 Technical data

 Voltage

220V±5%

 Frequency

50/60HZ

 Extruding Power

800W/1020W

Hot air power

1600W/3400W

 Welding rod heating power

800W

Air temp.

20-600℃ Adjustable

 Extruding temp.

200-300℃ Adjustable

Welding speed

2.0-2.5kg/h

Welding Rod DIA.

3.0-4.0MM

Weight

5.5-7.5kg



Extruding Power

800W

800W

1020W

1020W

Hot air power

1600W

3400W

1600W

3400W

Welding speed

2.0KG/h

2.0KG/h

2.5KG/h

2.5KG/h

Welding Rod DIA.

3.0-3.5mm

3.0-3.5mm

3.0-4.0mm

3.0-4.0mm

Weight

5.5kg

6.0kg

7.0kg

7.5kg






After-sales service

1.In order to provide customers with comprehensive technical support,we will provide technical and other related information upon request in a timely manner.

2.In required,we will appoint specialized technicians to the construction site to give technical trainings to construction people,and offer technical guidance throughout the whole construction process.

3.For damage due to shipment and delivery,after we receive the complaint,we will check the issure through provided pictures and videos.If our responsibility is confirmed,we wil offer free replacement.

4.When the construction is completed,as your request,our technical staff may participate in the final acceptance.
