Biaxial Plastic Geogrid
Geogrid is divided into: Fiberglass geogrid, Polyester geogrid, Steel plastic geogrid, PP weld geogrid, Uni-direction Plastic geogrid, Bia-direction Plastic geogrid.
Product Introduction
Biaxial plastic Geogrid
Geogrid is divided into: Fiberglass geogrid, Polyester geogrid, Steel plastic geogrid, PP weld geogrid, Uni-direction Plastic geogrid, Bia-direction Plastic geogrid.
Specification
TGSG15-15 TO TGSG40-40
HBP15-15MS TO HBP40-40MS
Properties
Homogenous structure, low creepage, anti-aging and resistance, acid and alkaline.
Usage
Make reinforce treatment for various kinds of soft soil foundation to evenly distribute load stress and reduce uneven settlement, not easy to generate static elctricity, and flammability property good in the coal mine. It is easy to wash coal. Used in highway, railway, port, airport and municipal project. Support in the recovery working face of coal mine and roadway in the coal mine.
Size of package
Width 4m, length 50-100m
Technical specification of Biaxial Plastic Geogrid
Item | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 | TGSG45-45 | TGSG50-50 |
g/m2 Unite weight | 300±30 | 330±30 | 400±40 | 300±30 | 500±50 | 600±50 |
M Width | ||||||
KN/m Tensile yield force per meter | 15 | 20 | 30 | 40 | 45 | 50 |
%≤ Elongation ratio（MD） | 15 | |||||
%≤ Elongation ratio（TD） | 13 | |||||
KN/m 2% Time elongation ratio drawing force（MD&TD） | 5 | 7 | 10.5 | 14 | 16 | 17.5 |
KN/m 5% Time elongation ratio drawing force（MD&TD） | 7 | 14 | 21 | 28 | 32 | 35 |
Our factory show
Pictures
Our certificates
Payment and delivery
Our advantage
Customer visits
Thanks for your visit, if you have any requirement about our product, just feel free to contact us as the following contact method.
Contact us
