Geomembrane

PVC Geomembrane

Product name: PVC geomembrane.
Material: PVC resin..
Thickness: 0.30 mm, 0.50 mm, 0.60 mm, 0.80mm, 1.00 mm, 1.50 mm, 2.00 mm..
Width: 2000 mm or more than 2000 mm..
Color: black or at customized....Chat Now

PVC geomembrane is polyvinyl chloride waterproof board. It is a kind of superior quality, high polymer waterproof sheet. By adding plasticizer, anti ultraviolet agent, anti aging agent, stabilizer and other processing aids into PVC resin, through extrusion method to produce molding high polymer waterproof coiled material. Composite PVC geomembrane is formed by PVC sheets and geotechnical cloth. With the advantages of high tensile strength, high and low temperature resistance and good thermal performance, roll seams can use cold sticking method or hot air welding method, which leads to form joint bond firmly, closed tight overall waterproof layer. PVC geomembrane can satisfy the water conservancy, municipal, construction, transportation, subways, tunnels and other civil engineering anti-seepage, separation, reinforcement and anti crack conditions.


Specifications:

·  Product name: PVC geomembrane.

·  Material: PVC resin.

·  Thickness: 0.30 mm, 0.50 mm, 0.60 mm, 0.80mm, 1.00 mm, 1.50 mm, 2.00 mm.

·  Width: 2000 mm or more than 2000 mm.

·  Color: black or at customized.


Features:

·  Easy for welding.

·  Low cost and long service life.

·  Convenient and quick construction.

·  Environmental friendly and non-toxic material.

·  Good physical property and mechanic strength.

·  High tearing resistance and strong deformation adaptability.

·  Excellent anti-aging, anti ultraviolet, anti decomposition ability.

·  Good weather resistance, high and low temperature resistance.

·  Good waterproof, drainage, anti-seepage and damp proof effects.

·  Perfect resistance to puncture performance, can resist most of the plant roots.

·  Excellent stability, acid and alkali, salt solution, oil, alcohol and other 80 kinds of chemical medium corrosion.

·  LDPE geomembrane is suitable for environmental sanitation, water conservancy, municipal engineering, garden, landscape, petrochemical, mining, salt industry, agriculture, aquaculture waterproof and anti leakage.

·  It is also applicable in living landfill yard, sewage treatment plant, power plant, adjusting tank, industrial and hospital solid waste, the building basement, underground warehouse, underground garage, docks and so on.


Number

Item

Index

1

Density g/cm3

1.25~1.35

2

Tensile strength (vertical and horizontal), MPa

≥15/13

3

Elongation at break (vertical and horizontal), %

≥220/200

4

Tear strength (vertical and horizontal), N/mm

≥40

5

Low temperature bending (-20℃)

No cracks

6

Dimensional change rate (vertical and horizontal), %

≤5

7

Permeability coefficient,cm/s

≤10﹣¹¹

8

Permeability coefficient(㎝3*㎝)

By design or contract

9

Heat aging treatment

Exterior

No bubbles, no adhesion, no holes

Relative change in tensile strength,%

≤25

Relative elongation at break, %

≤25

Low temperature bending (-20℃)

No crack


Applications:
PVC geomembrane with excellent easy welding and good hot melt performance is widely used in various building engineering, for example:

·  Reservoir, pool, dam and sewage treatment for anti-seepage.

·  Tunnel, expressway, bridge, landfill and artificial lake.

·  Roofing, light steel roofing and other industrial and civil large roof panel.

·  Ground engineering that needs certain corrosion resistance requirements.

·  Rigid layer waterproof layer and old building concrete component layers repairment.

·  Sewage treatment system, basement or underground works waterproof and moisture proof.

·  Water conservancy, municipal, construction, traffic, subway, tunnel engineering for anti seepage, isolation, reinforcement and anti crack.


image005_副本


WHY XINYU GEOSYNTHETICS ENGINEERING PRODUCT?

XINYU Geosynthetics aims to provide integrated, innovative and geosynthetic-related products and services to global engineering tasks. With an Accurate, Collaborative and Efficient approach, XINYU constantly strives to meet customer’s expectation and requirement through our expertise and experience to provide the most suitable product and service. We consider XINYU Geosynthetics a qualified products provider, a trusted business partner and a socially responsible company.


image006_副本


image006_副本2


After-sales service

1.In order to provide customers with comprehensive technical support,we will provide technical and other related information upon request in a timely manner.

2.In required,we will appoint specialized technicians to the construction site to give technical trainings to construction people,and offer technical guidance throughout the whole construction process.

3.For damage due to shipment and delivery,after we receive the complaint,we will check the issure through provided pictures and videos.If our responsibility is confirmed,we wil offer free replacement.

4.When the construction is completed,as your request,our technical staff may participate in the final acceptance.
